DrayTek V166-K Vigor 166 G.FAST and VDSL2 Ethernet Modem/Bridge

DrayTek Vigor V166-K G.fast & VDSL2 Modem

The DrayTek Vigor V166-K is a high-performance G.fast and VDSL2 modem designed to bridge ultrafast and superfast fibre (DSL) connections to your router or firewall. It arrives pre-configured for most UK ISPs and supports both IPv4 and IPv6.

Key Features

• G.fast & VDSL2 Modem
• Supports G.fast (Ultrafast Fibre) and VDSL2 (Superfast Fibre)

• Bridges DSL directly to Ethernet for use with your existing router or firewall

• High-Speed Performance

• Up to 330 Mbps download and 50 Mbps upload with G.fast technology
• G.fast & VDSL2 35b SuperVectoring capable

• Compatible with the latest DSL standards, with Vectoring and 35b SuperVectoring

• Dual Gigabit LAN Ports

• 2 x Gigabit (10/100/1000 Mbps) LAN ports

• Connect two devices without disconnecting the Ethernet WAN to check connectivity

• Plug-and-Play with Most ISPs

• Works as a modem with most ISPs straight out of the box
• Pre-configured for most UK ISPs

• Simply set the username and password on your router

• Flexible Operating Modes

• Full-bridge DSL to Ethernet modem mode

• Mini router mode with NAT and DMZ Host

• IPTV & VoD Ready

• Compatible with IPTV and Video on Demand services (YouView, Sky Q)

• IPv4 & IPv6 Support

• Fully compatible with both IPv6 and IPv4 networks

• Installation Options

• Wall or shelf mountable

• Mounting kit included

• Optional VigorCare

• Optional VigorCare support service available

Ideal for Router Integration

• Adds DSL connectivity to any router
• Ideal partner for DrayTek dual-WAN products or any Ethernet WAN firewall
• Reports DSL line status on DrayTek Vigor routers

Technical Specifications

Physical Interfaces

Performance

WAN Features

• Pre-configured with OpenReach network VLAN tag 101
• WAN1 Service & Customer (double-tag) VLAN support
• Maximum MTU 1508

G.fast & DSL Compatibility

• BT Infinity Option 1 & Option 2 compatible
• Compliant with Openreach SIN 527 & SIN 498
• Auto detection of G.fast and VDSL line modes
• Support for G.INP & Vectoring

G.fast Standards:

• ITU-T G.9700, G.9701 G.fast
• Profile: 106 MHz

VDSL Standards:

• ITU-T G.993.1 VDSL
• ITU-T G.993.2, G.997.1 VDSL2
• Band Plan: G.998, G.997
• Annex A, Annex B, Annex C
• VDSL2 Profiles: 8a, 8b, 8c, 8d, 12a, 12b, 17a, 35b
• OLR, UPBO, DPBO supported
• US0 supported
• Loop Diagnostic Mode
• DSL Forum WT-114

ATM Protocols:

• RFC-2684 / RFC-1483 Multiple Protocol over AAL5
• RFC-2516 PPP over Ethernet
• RFC-2364 PPP over AAL5
• Support for RFC4638 for MTU up to 1500

Network Features

• DSL status display with DrayTek Vigor routers

Management Interfaces

• Web-based user interface (HTTP / HTTPS)
• CLI (Command Line Interface) via Web Console, Telnet or SSH
• Configuration backup / restore
• Firmware upgrade via Web Interface or TFTP

Router Mode – Firewall & NAT Features

• DMZ Host
• NAT Port Forwarding
• NAT Port Redirection
• ALG (Application Layer Gateway): SIP, RTSP, FTP, H.323
• VPN Pass-Through: PPTP, L2TP, IPsec
• Object-based IPv4 / IPv6 Firewall
• MAC Address Filter
• SPI (Stateful Packet Inspection) with FlowTrack mechanism
• DoS / DDoS protection
• IP address anti-spoofing
• Bind IP to MAC address
• DHCP Server
• Static Route & IP Routed Subnet
• URL Keyword Filtering
• Dynamic DNS
• IGMP Proxy

Router Mode – WAN Protocols

• DHCP Client
• Static IP
• PPPoE / PPPoA
• IPv6: PPP, DHCPv6, Static IPv6, TSPC, AICCU, 6rd, 6in4 Static Tunnel
• Multi-PVC/VLAN virtual WAN interfaces for management / IPTV services

Router Mode – Management Features

• Syslog
• SNMP v2 & v3
• VigorACS Management
• TR-069
• TR-104
• NTP Client
• Built-in diagnostic tools (ping, traceroute)

Operating Requirements

• Wall mountable
• Operating Temperature: 0 °C ~ 45 °C
• Storage Temperature: -25 °C ~ 70 °C
• Humidity: 10% ~ 90% (non-condensing)
• Power Consumption: 6.6 W max

Dimensions & Power

Box Contents

• Vigor 166 Modem
• Quick Start Guide
• RJ-11 DSL Cable
• Cat-5e RJ-45 Cable
• Screws & wall plugs for wall mounting
• DC 12 V PSU
