TP-Link Omada ER706W-4G 4G+ Cat6 AX3000 Gigabit VPN Router
$363.00
TP-Link Omada ER706W-4G AX3000 Gigabit VPN Router with 4G+ Cat6
The TP-Link Omada ER706W-4G is a high-performance AX3000 Gigabit VPN router designed for flexible 4G+ connectivity, secure VPN performance, and centralized cloud management via the Omada platform.
Key Features
- 4G+ Cat6 Connectivity
-
Insert a Nano SIM card to enjoy 4G+ Cat6 speeds of up to 300 Mbps downlink and 50 Mbps uplink.
-
AX3000 Dual-Band Wi-Fi 6
- 5 GHz: up to 2402 Mbps (HE160)
-
2.4 GHz: up to 574 Mbps
-
High-Speed Wired Networking
-
6 Gigabit Ethernet ports for reliable, high-speed wired connections.
-
Detachable High-Gain Antennas
-
5 high-gain detachable antennas to extend and concentrate Wi-Fi signals (3 Wi-Fi antennas, 2 LTE antennas).
-
Centralized Cloud Management
- Manage easily via Omada Cloud-Based Controller, Omada Hardware/Software Controller, and Omada app
-
Supports zero-touch provisioning, unified configuration, intelligent network monitoring, and abnormal event warnings.
-
Omada Mesh Support
-
Seamlessly connects to EAP access points that support mesh technology.
-
High-Security VPN
- Supports IPSec, SSL, WireGuard, OpenVPN, PPTP, and L2TP VPN.
4G Network Specifications
Network Type
-
4G LTE-FDD (EU Bands):
B1/B3/B5/B7/B8/B20/B28/B32
(2100/1800/850/2600/900/800/700/1450 MHz) -
4G LTE-TDD:
B38/B40/B41
(2600/2300/2500 MHz) -
3G: DC-HSDPA/HSPA+/HSDPA/HSUPA/WCDMA
B1/B3/B5/B8 (2100/1800/850/900 MHz)
Carrier Aggregation Combinations
- B1 + B1/B3/B5/B7/B8/B20/B28/B38/B40/B41
- B3 + B3/B5/B7/B8/B20/B28/B38/B40/B41
- B5 + B5/B7/B38/B40/B41
- B7 + B7/B8/B20/B28/B32
- B8 + B32/B38/B40/B41
- B20 + B32/B38/B40
- B28 + B32/B38/B40/B41
- B38 + B38
- B40 + B40
- B41 + B41
SIM Type
- 1 × Nano SIM card slot
4G Speed
- Downlink: 300 Mbps
- Uplink: 50 Mbps
Security Features
- DPI (Deep Packet Inspection)
- Application control via DPI
-
Updated application library
-
IDS/IPS
-
Signature-based IPS/IDS threat detection
-
Access Control & Filtering
- Source/Destination IP-based access control
- Web Group Filtering
-
URL Filtering
-
Web Security & ARP Protection
- ARP Inspection (sending GARP packets, ARP scanning)
-
IP-MAC binding
-
Attack Defense
- TCP/UDP/ICMP flood defense
- Block TCP scan (Stealth FIN/Xmas/Null)
-
Block ping from WAN
-
Wireless Encryption
- WPA/WPA2/WPA3 Personal
- WPA/WPA2/WPA3 Enterprise
Hardware Specifications
| Item | Specification |
|---|---|
| Interfaces | 1 × Gigabit SFP WAN/LAN port 1 × Gigabit WAN port 4 × Gigabit LAN/WAN ports |
| Supported Network Media | 10BASE-T: UTP Cat 3/4/5, STP (Max 100 m) 100BASE-TX: UTP Cat 5/5e, STP (Max 100 m) 1000BASE-T: UTP Cat 5/5e/6 (Max 100 m) |
| Button | Reset button |
| Power Supply | 12VDC / 2A power adapter |
| Wi-Fi Speeds | 2.4 GHz: 574 Mbps 5 GHz: 2402 Mbps (HE160) |
| Flash | 128 MB NAND |
| DRAM | 512 MB DDR4 |
| LEDs | SYS, WLAN, SFP, LTE Signal, WAN (1000M/100/10M Link/Act), WAN/LAN (1000M/100/10M Link/Act) |
| Dimensions (W × D × H) | 8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm), antenna dimensions not included |
| Antennas | Wi-Fi: 3 × dual-band detachable (5 GHz 5.5 dBi & 2.4 GHz 4.5 dBi) LTE: 2 × 4.0 dBi omnidirectional detachable |
| Mounting | Desktop / Wall-mounting |
| Max Power Consumption (EU) | 17.3 W |
Performance
| Feature | Performance |
|---|---|
| IPS Throughput (TCP/UDP) | TCP: 229 Mbps, UDP: 188 Mbps |
| DPI Throughput (TCP/UDP) | TCP: 933 Mbps, UDP: 927 Mbps |
| GRE Throughput | Unencrypted: 545.3 Mbps Encrypted: 282.6 Mbps |
| WireGuard VPN | 387.7 Mbps |
| Concurrent Sessions | 150,000 |
| New Sessions per Second | 5,100 |
| NAT (Static IP) | 947.1 Mbps / 940.1 Mbps |
| NAT (DHCP) | 949.2 Mbps / 941.1 Mbps |
| NAT (PPPoE) | 942.6 Mbps / 941.1 Mbps |
| NAT (L2TP) | 875.4 Mbps / 892.0 Mbps |
| NAT (PPTP) | 881.2 Mbps / 895.8 Mbps |
| IPsec VPN Throughput (AES256) | ESP-SHA1-AES256: 652.2 Mbps ESP-SHA256-AES256: 654.4 Mbps ESP-SHA384-AES256: 646.5 Mbps ESP-SHA512-AES256: 670.5 Mbps |
| OpenVPN Throughput | 115.5 Mbps |
| L2TP VPN Throughput | Unencrypted: 990.0 Mbps Encrypted: 475.0 Mbps |
| PPTP VPN Throughput | Unencrypted: 1177.9 Mbps Encrypted: 177.4 Mbps |
| SSL VPN Throughput | 122.5 Mbps |
| 66-Byte Packet Forwarding Rate | 1,453,489 pps / 1,453,488 pps |
| 1518-Byte Packet Forwarding Rate | 81,274 pps / 91,275 pps |
Wireless Features
- Seamless roaming
- Mesh (with EAP that supports Mesh)
- OFDMA
- Beamforming
- MU-MIMO
- Rate limit (based on SSID/client)
- Airtime fairness
- Wireless encryption: WPA/WPA2/WPA3 Personal, WPA/WPA2/WPA3 Enterprise
- Multiple SSIDs: 16 total (8 per radio)
- Guest network support
Basic Network Functions
- WAN Connection Types
- Static IP, Dynamic IP, PPPoE (supports MRU configuration), PPTP, L2TP
-
MAC clone, modify WAN address
-
DHCP
- DHCP Server
- DHCPv6 PD Server (only in Standalone Mode)
- DHCP options customization
-
DHCP address reservation
-
Multi-Network Support
- Multi-IP interfaces
-
Multi-Net DHCP
-
SMS
-
Receive / send SMS
-
IPv6 Support
-
Static IP / SLAAC / DHCPv6 / PPPoE / 6to4 Tunnel / PassThrough / Non-address mode
-
VLAN & IPTV
- 802.1Q VLAN
- IPTV: IGMP v2/v3 Proxy, Custom Mode, Bridge Mode
Advanced Functions
- ACL
-
IP/Port/Protocol/Domain name filtering
-
Advanced Routing
- Static routing
- Policy routing
- RIP
-
OSPF
-
Bandwidth Control
-
IP-based bandwidth control
-
Load Balance
- Intelligent load balance
- Application-optimized routing
- Link backup (timing, failover)
-
Online detection
-
NAT
- One-to-One NAT
- Multi-Net NAT
- Virtual server
- Port triggering
- NAT-DMZ
- FTP/H.323/SIP/IPSec/PPTP ALG
-
UPnP
-
Session Limit
- IP-based session limit
VPN Capabilities
- GRE
-
GRE support (only in Standalone Mode)
-
SSL VPN
-
50 tunnels
-
IPsec VPN
- 100 IPsec VPN tunnels
- LAN-to-LAN, Client-to-LAN
- Main, Aggressive negotiation modes
- DES, 3DES, AES128, AES192, AES256 encryption
- IPsec failover
- IKE v1/v2
- MD5, SHA1, SHA2-384, SHA2-512 authentication
- NAT Traversal (NAT-T)
- Dead Peer Detection (DPD)
-
Perfect Forward Secrecy (PFS)
-
PPTP VPN
- PPTP VPN server
- PPTP VPN client (10)
- 50 tunnels
-
PPTP with MPPE encryption
-
L2TP VPN
- L2TP VPN server
- L2TP VPN client (10)
- 50 tunnels
-
L2TP over IPsec
-
OpenVPN
- OpenVPN server
- OpenVPN client (5)
- 55 OpenVPN tunnels
- “Certificate + Account” mode
-
Full mode
-
WireGuard VPN
- 20 tunnels
Authentication & Captive Portal
- Web authentication modes:
- No Authentication
- Simple Password
-
Hotspot (Local User / Voucher / SMS / Radius)
-
External integration:
- External Radius server
- External portal server
- LDAP
Management & Omada Integration
- Omada App: Yes
- Centralized Management:
- Omada Cloud-Based Controller
- Omada Hardware Controller (OC300, OC200)
-
Omada Software Controller
-
Cloud Access: Yes
-
Service & Maintenance
- Dynamic DNS: Dyndns, No-IP, Peanuthull, Comexe, DDNS customization
- Web management interface
- Remote management
- Export & import configuration
- SNMP v1/v2c/v3
- Diagnostics (Ping & Traceroute)
- NTP synchronize
- Port mirroring
- CLI (only in Standalone Mode)
-
Syslog support
-
Zero-Touch Provisioning: Yes (requires Omada Cloud-Based Controller)
-
Management Features
- Automatic device discovery
- Intelligent network monitoring
- Abnormal event warnings
- Unified configuration
- Reboot schedule
- Captive portal configuration
Other Information
-
Certification: CE, FCC, RoHS
-
Package Contents
- ER706W-4G
- Power adapter
-
Quick Installation Guide
-
System Requirements
- Microsoft Windows 98SE, NT, 2000, XP, Vista, Windows 7/8/8.1/10/11
-
MAC OS, NetWare, UNIX, or Linux
-
Environment
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Storage Temperature: -40°C to 70°C (-40°F to 158°F)
- Operating Humidity: 10% to 90% non-condensing
- Storage Humidity: 5% to 90% non-condensing
